Page 148 - Bürkert

Envelope Dimensions [mm] (see datasheet for details)
32
5/2-way valves, circuit function H 32 5/2-way valves, circuit function L and N
SW 14 SW14
G1/8 76 G1/8 76
Moulded calble Moulded calble
(Standard 3 m long) (Standard 3 m long)
11,2 11,2 3 - 3 deep G1/4 / NPT 1/4 6519 Ex m

G1/4 / NPT1/4 G1/4 / NPT 1/4 26 G1/4 / NPT1/4 4,3 24

176,8 7,9 - 4,2 deep 43 28,5

4,3 250,2 24 4,5 11 - 3 deep 70 36 112 48
36 4,3 107,7 28,5 50 26,5
24 8 - 4,3 deep 32 48 44
26,5
39,6

3 43 24 3 - 3 deep
24 53
32

Ordering table

Seal material Port connec- Pressure Voltage/
Orifice QNn-value Mass Nominal
Circuit function (Body tion threaded range frequency Item no.
2)
1)
[mm] air [l/min] [g] power [W]
material) port [inch] [bar] [V/Hz]
Type 6519 threaded version Ex m – thread insert material brass, threaded port 1, 3 and 5 can also be flanged; with moulded cable, 3 m
3) 4)
long
H 5/2-way valve, 8.0 NBR and PUR G 1/4 1300 2 - 8 700 3 024/UC 134 722
servo-assisted, in de- (Polyamide)
energized 110/UC 134 723
position port 2 pres-
230/UC 134 724
surized,
port 4 exhausted
L 5/3-way valve, 9.0 NBR G 1/4 1300 3 - 10 1.100 3 024/UC 278 221
servo-assisted, in (Aluminium)
110/UC 134 726
middle
position all ports
230/UC 134 727
locked
N 5/3-way valve, 9.0 NBR G 1/4 1300 3 - 10 1.100 3 024/UC 278 222
servo-assisted, in (Aluminium)
110/UC 134 729
middle
position ports 2 and 4
230/UC 134 730
exhausted
1) Flow rate: QNn value air [l/min]: Measured at +20 °C, 6 bar pressure at valve inlet, 1 bar pressure difference
2) Pressure values [bar]: Gauge pressures with respect to the prevailing atmospheric pressure
3) Versions with terminal box on request
4) Circuit function H (5/2 way) as impulse version on request
