Plunger Operated 3/2-way Solenoid Valve
for high temperatures

0355 G 1/4”

• Seat valve direct acting
• Medium temperature up to +180 °C
• Push-over solenoid system
• For gases and fluids

2(A)

1(P) 3(R)

Direct-acting plunger solenoid, Type 355, for neutral gases and liquids. Envelope Dimensions [mm]
Also suitable for high temperatures, such as hot water, hot air, steam.

Technical Data B
Orifice DN2-4 mm
Body material Brass with stainless steel seat 1.4305,
Stainless steel 1.4581
Coil material Epoxy
Coil isolation class H
Inner part valve Stainless steel
Seal material NBR, FKM, PTFE, EPDM
Medium
NBR Neutral fluids, hydraulic oil, oil without additives
EPDM Oil and fat-free fluids
FKM Per-solutions, hot oils with additives
PTFE Steam, organic solvents
Medium temperature
NBR -10 °C to +90 °C
EPDM -40 °C to +130 °C
FKM 0 °C to +130 °C C
PTFE -40 °C to +180 °C
Ambient temperature Max. +55 °C
Voltage tolerance ±10%
Duty cycle 100% continuous rating
Electrical connection Tag connector acc. to DIN EN 175301-803 Form A
(previously DIN 43650) for cable plug Type 2508 A
(supplied as standard)
Power consumption v
Inrush
Hold (hot coil) AC: 35-40cv VA
AC: 16 VA, 10 W DC: ca. 12 W A B C
Protection class IP 65 with cable plug 56 45.5 111.5
Installation as required, preferably with actuator upright

Options
• Circuit function D and E on request
• UL, UR and CSA approval
