high quality build accessories suitable for our wide range of products across all markets. Please check data
sheets respectively for Series 1 and Series X products as they may not be interchangeable between eachother.
a = Series X Displays / Multi Vision Displays, B = Series X Panel Computers, c = Series 1 Displays, D = Computers,
e = MIL Qualified Displays, f = Series X Generation 2 (G2) Displays, G = Series X Generation 2 (G2) Panel Computers

Mounting Brackets - Desktop, ceiling, console, wall, rack or cabinet mounting brackets and plates.
typenUMBeR DescRiption sUitaBLe foR iD
HD CMB SX1-A2 Console / Panel Mounting Bracket Kit (key hole). 1.0-12.75mm 12, 15, 17, 19 inch AB
HD CMB SX1-A3 Console / Panel Mounting Bracket Kit (key hole). 1.0-12.75mm 12, 15, 17, 19 inch AB
+ Features longer screws for easier mounting.
HD CMB SX1-B1 Console / Panel Mounting Bracket Kit. 24, 27, 32 inch AB
HD CMB SX1-C1 Console / Panel Mounting Bracket Kit. 26 inch AB
HD CMB SX2-A1 Console / Panel Mounting Bracket Kit. 15, 17, 19 inch FG
HD TMB SX2-A2 Console / Panel Mounting Bracket Kit. 32 inch A
HD TMB SX1-A1 Table Mounting Bracket. EN60945 Tested. 12, 15 inch AB
HD TMB SX1-B1 Table Mounting Bracket. EN60945 Tested. 17, 19 inch AB
HD TMB SX1-C1 Table Mounting Bracket. EN60945 Tested. 24, 26,27 inch AB
HD TMB SX2-A1 Table Mounting Bracket. EN60945 Tested. 15, 17, 19 inch FG
HD WBK SX1-A1 Wall Mount Box Kit 8 inch AB
HT 00226 OPT-A1 Desktop/Wall/Ceiling/Cabinet for Computers. HT C02, HM C02 D
HT 00228 OPT-A1 Desktop/Wall/Ceiling/Cabinet for Computers. With Cable Reliefs. HT B17, HT B18, D
HT B22
HT 00270 OPT-A1 Bracket Kit Desktop/Wall/Ceiling/Cabinet for Computers. HT B22 D
JH 15TBR STD-B1 Desktop/Ceiling Bracket for Displays. 15 inch C
JH MMDBR STD-A1 Desktop/Ceiling Bracket for Displays. 19, 20 inch CE
JH 19TBR STD-B1 Desktop/Ceiling Bracket for Displays. 19 inch Slim C
JH 19BRD STD-A1 Desktop/Ceiling Bracket for Displays. EN60945 Tested. 19 inch CE
JH 22TBR STD-A1 Desktop/Ceiling Bracket for Displays. 22 inch C
JH 22BRD STD-A1 Desktop/Ceiling Bracket for Displays. EN60945 Tested. 22 inch C
JH 23TBR T01-A1 Desktop/Ceiling Bracket for Displays. 23 inch C
JH 23BRD STD-A1 Desktop/Ceiling Bracket for Displays. EN60945 Tested. 23 inch C
Rotary Brackets - For use with Mounting Brackets.
typenUMBeR DescRiption sUitaBLe foR iD
JH 15TRO STD-A1 Suitable for Displays. 15 inch C
JH MMDRO STD-A1 Suitable for Displays. 19, 20, 22, 23, 26 inch CE
Vesa Brackets - For Wall or Ceiling mounting, compatible with several VESA sizes.
typenUMBeR DescRiption sUitaBLe foR iD
HD VED SX1-A1 Suitable for Displays and Panel Computers. 12, 15, 17, 19, 24, 26 inch AB
HD VED SX2-A1 Suitable for Displays and Panel Computers. 15 inch FG
HD VED SX2-B1 Suitable for Displays and Panel Computers. 17 inch FG
HD VED SX2-C1 Suitable for Displays and Panel Computers. 19 inch FG
HD VED SX2-D1 Suitable for Displays and Panel Computers. 24 inch FG
HD VED SX2-E1 Suitable for Displays and Panel Computers. 26 inch FG
HD VED SX2-F1 Suitable for Displays and Panel Computers. 27 inch FG
HD VED SX2-G1 Suitable for Displays. 32 inch A
JH 15VED STD-A1 Suitable for Displays. 15 inch C
JH 19VED STD-A1 Suitable for Displays. 19 inch CE
JH 19VED STD-B1 Suitable for Displays. 19 inch Slim C
JH 20VED STD-A1 Suitable for Displays. 20 inch CE
JH 22VED STD-A1 Suitable for Displays. 22 inch C
JH 23VED STD-A1 Suitable for Displays. 23 inch C

Water covers - For top of product. IP22 Rated.
typenUMBeR DescRiption sUitaBLe foR iD
JH 15TWC STD-A1 Suitable for Displays. 15 inch C
JH 19TWC STD-B1 Suitable for Displays. 19 inch CE
JH 19TWC STD-C1 Suitable for Displays. 19 inch Slim C
JH 20TWC STD-B1 Suitable for Displays. 20 inch CE
JH 22TWC STD-A1 Suitable for Displays. 22 inch C
JH 23TWC STD-A1 Suitable for Displays. 23 inch C
