Ordering Chart
Assembly Electrical Analogue 2 Binary Binary Control
variations Communication connection feedback outputs input function Item no.
NAMUR IEC 534-6 VDI / VDE 3845
no Cable gland no no yes single and 206 593
double-acting
no yes yes single and 206 595
double-acting
yes yes yes single and 206 594
double-acting
Profibus DPV1 Multipole via Bus no yes single and 206 600
double-acting
via Bus yes yes single and 206 601
double-acting
REMOTE
ELEMENT Actuator Ø 70 mm/90 mm no Cable gland no yes yes single-acting 224 873
CLASSIC Actuator Ø 80 mm/100 mm
yes yes yes single-acting 224 872

ELEMENT Actuator Ø 130 mm no Cable gland no no yes single and 206 607
CLASSIC Actuator Ø 125/175/225 mm double-acting
no yes yes single and 206 609
double-acting
yes yes yes single and 206 608
double-acting

Accessories

Description Item no.
Assembly bridge VDI / VDE 3845, Stainless steel 770 294

Adapter kit VDI / VDE 3845, Stainless steel 787 338
Adapter kit linear actuators IEC 534-6, stainless steel 787 215

Silencer G 1/4” (replacement part) 780 780

M12 socket, 8-pin, 2 m cable set 919 061
M8 plug, 4-pin for binary outputs, without cable 917 131

Feedback unit for end positions 2, PNP proximity switches 677 218
Remote Version
Bracket for wall mounting, Stainless steel 675 715

Holder for DIN-Rail assembly AI/Stainless steel 675 702
Remote position sensor control valves CLASSIC Type 27xx 211 535

Remote position sensor control valves CLASSIC Type 23xx 212 360
Adapter kit for remote position sensor control valves Type 23xx 679 917

Adapter kit for remote position sensor control valves Type 27xx
Actuator size Ø 80 mm 679 943

Actuator size Ø 100 mm / Ø 125 mm 677 215

Actuator size Ø 175 mm / Ø 225 mm 677 217
