Digital electropneumatic Process Controller

8793

• Compact metal housing
• Graphic display with backlight
• Easy start-up of process controller
and positioner

• Comprehensive range of additional
software functions
• Mounting acc. to IEC 534-6/VDI VDE
3845

The robust and compact process controller is designed to standardisa- Envelope Dimensions [mm] (see datasheet for details)
tion acc. to IEC 534-6 or VDI/VDE 3845 for assembly with linear and
rotary actuators. In addition, the remote version can be combined with Standard Version
Ø50 4 x M8
Bürkert process control valves. The digital electropneumatic SideCon- 4 x M6
trol process controller can be operated by the usual current and voltage
standard signals and can also be equipped with the Fieldbus interface 4x90° 45°
PROFIBUS DPV1. Additional to the digital display the valve opening is
signalled by a mechanical indicator element. The actual process value is 7,5 65
directly supplied to the device as 4-20 mA, PT100 or as frequency signal.
The process controller calculates the position setpoint for the subordi-
nated positioner through the variance comparison. Due to the analogue
feedback all analogue values on the controlling level can be transferred. 25
The parameterization of process controller and positioner can be carried 60
out automatically.

Technical Data Remote Version
Material: Body Aluminium plastic-coated
Seal EPDM, NBR, FKM
Operating voltages 24 VDC +/-10%
Residual ripple max. 10%
Setpoint setting 0/4 to 20 mA and 0 to 5/10 V
45
Input resistance 0/4 to 20 mA: 180 Ω 2x M4
0 to 5/10 V: 19 kΩ
Input data for actual value signal
Setting 4 - 20 mA 180 Ω Input resistance / Resolution 12 bit
Frequency setting 17 kΩ Input resistance, 35
0 - 1000 Hz / 1%0 o.R. measuring range,
Input signal > 300 mV88
Setting Pt 100 Signal form Sine, rectangle, triangle
Measuring range -20 ºC - +220 ºC,
Resolution < 0.1 ºC, M
Analogue feedback 4-20 mA, 0-20 mA Ambient temperature 0 °C to +60 °C
0-10 V, 0-5 V Pilot air ports Threaded port G 1/4”
Binary input galvanically isolated, 0-5 V = log “0”, 10-30 Supply pressure 1.4 to 7 bar 1)
V = log “1” Air input filter Exchangeable (aperture size ~0.1 mm)
Binary Output 2 Outputs (optional), galvanically isolated Pilot valve system Single and double-acting up to 150 l /min.
N
2)
Current limit 100 mA, Output will be synchronised when Air capacity 95 l /min (with 1.4 bar ) for aeration and
N
overloaded ventilation
2)
Control medium Neutral gases, air DIN ISO 8573-1 150 l /min (with 6 bar ) for aeration and
N
Dust concentration Class 5 (<40 µm particle size) ventilation
Particle density Class 5 (<10 mg/m ) (QNn = 100 lN/min (acc. to the definition
3
Pressure condensation point Class 3 (<-20 °C) with decrease in pressure from 7 to 6 bar
3
Oil concentration Class 5 (<25 mg/m ) absolute)
Position detection module Potentiometer, max. angle 180°
1) The supply pressure has to be 0.5-1 bar above the minimum required pilot pressure for the
valve actuator
2) Pressure specifications: Overpressure with respect to atmospheric pressure
