SPECIFICATIONS

Description: Industrial 8-port slim type unmanaged Gigabit PoE Ethernet switch

Features: Provide 8x10/100/1000Base-T(X) PoE (P.S.E.) ports, P.S.E. based on IEEE 802.3at standard up to 30 Watts per port, jumbo
frame up to 9KBytes, auto-negotiation and auto-MDI/MDI-X, full/half-duplex transmission, store and forward transmission,
flow control, Rigid IP-30 housing design, DIN-Rail and wall mounting enabled

Physical Ports: 8 x 10/100/1000Base-T(X) Ports in RJ45 With P.S.E.
Ethernet IEEE 802.3 for 10Base-T, IEEE 802.3u for 100Base-TX, IEEE 802.3ab for 1000Base-T, IEEE 802.3x for Flow control, IEEE
Standards: 802.3at PoE specification (up to 30 Watts per port for P.S.E.).
Switching Bandwidth: 16Gbps. MAC Table: 4K MAC addresses.
Processing: Store-and-Forward. Jumbo Frame: Up to 9KBytes
DIP-Switch: DIP-Switch 1: Power-1 failed warning : (ON) enable, (OFF) disable
DIP-Switch 2: Power-2 failed warning : (ON) enable, (OFF) disable
LED Indicators: Power indicator Green: Power LED x 2, Fault indicator Amber: Indicate PWR1 or PWR2 failure, 10/100/1000Base-T(X)
RJ45 port indicator and PoE indicator Green for port Link/Act at 1000Mbps / Amber for port Link/Act at 10/100Mbps,
Green for PoE power injected.
Fault Contact: Relay output to carry capacity of 1A at 24VDC

Power: Redundant Input power: Dual DC inputs. 50 ~ 57VDC on 6-pin T. Block
PoE output power: 180 Watts
Power consumption (Typ.): 6 Watts (PoE output not included)
Overload current protection: Present
Reverse polarity protection: Present
Physical: Enclosure: IP-30. Weight: 442 g
Dimension (W x D x H):
26.1 (W) x 94.9 (D) x 144.3(H) mm (1.03 x 3.74 x 5.68”)
Environmental: Storage Temperature: -40 to 85°C (-40 to 185°F)
Operating Temperature: -40 to 75°C (-40 to 167°F)
Operating Humidity: 5% to 95% Non-condensing
Regulatory EMC: CE EMC (EN55024,EN 55032), FCC Part 15 B
approvals: EMI: EN55032, CISPR 32, EN61000-3-2, EN61000-3-3, FCC Part 15 B class A
EMS: EN55024 (IEC/EN 61000-4-2 (ESD), IEC/EN 61000-4-3 (RS), IEC/EN 61000-4-4 (EFT), IEC/EN61000-4-5 (Surge),
IEC/EN 61000-4-6 (CS), IEC/EN 61000-4-8 (PFMF), IEC/EN 61000-4-11 (DIP))
Shock: IEC60068-2-27, Free Fall: IEC60068-2-31
Vibration: IEC60068-2-6, Safety: EN60950-1 compliant HN GP1080A
MTBF / Warranty: 665276 hrs / 5 years
