Page 8 - Hatteland Technology 2019

SPECIFICATIONS

Description: Industrial 12-port slim type managed Gigabit Ethernet switch
Features: Supports recovery time<30ms and MSTP(RSTP/STP compatible) for Ethernet Redundancy, Allows multiple redundant network rings, Supports
standard IEC 62439-2 MRP (Media Redundancy Protocol)*, Supports IPV6 new internet protocol version, Supports Modbus TCP protocol,
* This function is Supports IEEE 802.3az Energy-Efficient Ethernet technology, Provided HTTPS/SSH protocol to enhance network security, Supports SMTP client
available by request and NTP server protocol, Supports IP-based bandwidth management, Supports application-based QoS management, Supports Device Binding
only security function, Supports DOS/DDOS auto prevention, IGMP v2/v3 (IGMP snooping support) for filtering multicast traffic.
Physical Ports: 8 x 10/100/1000Base-T(X) with P.S.E. Ports in RJ45 Auto MDI/MDIX
4 x 100/1000Base-X with SFP port
Ethernet IEEE 802.3 for 10Base-T, IEEE 802.3u for 100Base-TX and 100Base-FX, IEEE 802.3ab for 1000Base-T, IEEE 802.3z for 1000Base-X, IEEE 802.3x
Standards: for Flow control,IEEE 802.3ad for LACP (Link Aggregation Control Protocol ), IEEE 802.1p for COS (Class of Service), IEEE 802.1Q for VLAN
Tagging, IEEE 802.1D for STP (Spanning Tree Protocol), IEEE 802.1w for RSTP (Rapid Spanning Tree Protocol), IEEE 802.1s for MSTP (Multiple
Spanning Tree Protocol) ,IEEE 802.1x for Authentication, IEEE 802.1AB for LLDP (Link Layer Discovery Protocol), MAC Table: 8192 MAC
addresses, Priority Queues: 8, Processing: Store-and-Forward, Share Data Buffer: 4Mbit, Switch Properties: Switching latency: 7 us, Switching
bandwidth: 24Gbps, Throughput (packet per second): 17.856Mpps@64Bytes packet, Max. Number of Available VLANs: 4096, VLAN ID Range:
VID 0 to 4095, IGMP multicast groups: 256 for each VLAN, Port rate limiting: User Define, Jumbo frame: Up to 9.6k bytes, Security Features:
Device Binding security feature, Enable/disable ports, MAC based port security, Port based network access control (802.1x), VLAN (802.1Q ) to
segregate and secure network traffic, Radius centralized password management, SNMPv3 encrypted authentication and access security,
Https / SSH enhance network security, Software Features: STP/RSTP/MSTP (IEEE 802.1D/w/s), Redundant Ring (O-Ring) with recovery time
less than 20ms over 250 units, TOS/DiffServ supported, Quality of Service (802.1p) for real-time traffic, VLAN (802.1Q) with VLAN tagging,
IGMP Snooping, IP-based bandwidth, management, Application-based QoS management, DOS/DDOS auto prevention, Port configuration,
status, statistics, monitoring, security, DHCP Server/Client/Relay, SMTP Client, Modbus TCP, Ethernet/IP™, NTP server, Network Redundancy:
O-Ring, Open-Ring, O-Chain, MRP*NOTE, MSTP (RSTP/STP compatible), RS-232 Serial Console Port: RS-232 in RJ45 connector with console
cable. 115200bps, 8, N, 1
DIP-Switch: None
LED Indicators: Power Indicator (PWR): Green: Power LED x 3. Ring Master Indicator (R.M.): Green: Indicates that the system is operating in O-Ring Master
mode. Ring Indicator (Ring): Green: Indicates that the system operating in O-Ring mode, Green Blinking: Indicates that the Ring is broken.
Fault Indicator (Fault): Amber: Indicate unexpected event occurred. 10/100/1000Base-T(X) RJ45 Port Indicator: Green for Port LINK/ACT
indicator, Dual color LED for speed indicator: Green for 1000Mbps / Amber for 100Mbps / off-light for 10Mbps. 100/1000Base-X SFP Port
Indicator: Green for port Link/Act
Fault Contact: Relay output to carry capacity of 1A at 24VDC
Reset Function: < 5 sec: System reboot, > 5 sec: Factory default
Power: Redundant Input power: Dual DC inputs. 12 ~ 48VDC on 6-pin terminal block
Power consumption (Typ.): 13 Watts
Overload current protection: Present
Reverse Polarity Protection: Present
Hi-POT: 1.5KV AC
Physical: Enclosure: IP-30. Weight: 779g
Dimensions (W x D x H): 54.3 (W) x 108.3 (D) x 145.1 (H) mm (2.13 x 4.26 x 5.71 inch)
Environmental: Storage Temperature: -40 to 85°C (-40 to 185°F)
Operating Temperature: -40 to 75°C (-40 to 167°F)
Operating Humidity: 5% to 95% Non-condensing
Regulatory EMC: CE EMC (EN 55024, EN 55032), FCC Part 15 B
approvals: EMI: EN 55032, CISPR32, EN 61000-3-2, EN 61000-3-3, FCC Part 15 B class A
EMS: EN 55024 (IEC/EN 61000-4-2 (ESD: Contact 8KV, Air 10KV), IEC/EN 61000-4-3 (RS),IEC/EN 61000-4-4 (EFT Power 2KV, Single 2KV),
IEC/EN 61000-4-5 (Surge: Power 4KV, RJ45 4KV), IEC/EN 61000-4-6 (CS), IEC/EN 61000-4-8(PFMF), IEC/EN 61000-4-11 (DIP)) HN G9084-LA
Shock: IEC60068-2-27. Free Fall: IEC60068-2-31. Vibration: IEC60068-2-6. Safety: EN60950-1 compliant
MTBF / Warranty: 551378 hours / 5 years
