SPECIFICATIONS

Description: Industrial 12-port slim type layer2 managed Gigabit PoE Ethernet switch
Features: Support standard IEC 62439-2 MRP function, 8 port P.S.E. fully compliant with IEEE802.3at standard, provide up to 30 Watts per
port, PoE on/off scheduled configuration, IPV6 new internet protocol version, EtherNet/IP™ and Modbus TCP protocol, IEEE 802.3az
Energy-Efficient Ethernet technology, Provided HTTPS/SSH protocol to enhance network security, DOS/DDOS auto prevention, auto-
negotiation and auto-MDI/MDIX, SNMP v1/v2c/v3 & RMON & 802.1Q VLAN Network Management, Syslog/SNMP Trap notification
for warning of unexpected event, Web-based ,SNMP v1/v2c/v3, Telnet, Console (CLI), and Windows utility (Open-Vision)
configuration, Robust EMS design, provide 8K ESD and 4KV Surge protection, Rigid IP-30 housing design, DIN-Rail and wall mounting
enabled
Physical Ports: 8 x 10/100/1000Base-T(X) with P.S.E. Ports in RJ45 Auto MDI/MDIX
4 x 100/1000Base-X with SFP port, generic version
Ethernet IEEE 802.3 for 10Base-T, IEEE 802.3u for 100Base-TX and 100Base-FX, IEEE 802.3ab for 1000Base-T, IEEE 802.3z for 1000Base-X,
Standards: IEEE 802.3x for Flow control, IEEE 802.3ad for LACP (Link Aggregation Control Protocol), IEEE 802.1p for COS (Class of Service), IEEE
802.1Q for VLAN Tagging, IEEE 802.1D for STP (Spanning Tree Protocol), IEEE 802.1w for RSTP (Rapid Spanning Tree Protocol), IEEE
802.1s for MSTP (Multiple Spanning Tree Protocol), IEEE 802.1x for Authentication, IEEE 802.1AB for LLDP (Link Layer Discovery
Protocol), IEEE 802.3at PoE specification (up to 30 Watts per port for P.S.E.)
DIP-Switch: None
LED Indicators: Power Indicator (PWR) Green: Power LED x 3, Ring Master Indicator (R.M.) Green: Indicates that the system is operating in O-Ring
Master mode, O-Ring Indicator (Ring) Green: Indicates that the system operating in O-Ring mode, Green Blinking: Indicates that the
Ring is broken, Fault Indicator (Fault) Amber: Indicate unexpected event occurred, 10/100/1000Base-T(X) RJ45 Port Indicator Green
for Port LINK/ACT indicator, Dual color LED for speed indicator: Green for 1000Mbps / Amber for 100Mbps / off-light for 10Mbps,
100/1000Base-X SFP Port Indicator Green for port Link/Act, PoE. Indicator Green: PoE enabled LED x 8.
Fault Contact: Relay output to carry capacity of 1A at 24VDC
Power: Redundant Input power: 50/57VDC on 6-pin T. Block
Power consumption (Typ.): 13.2 Watts
PoE Power Budget: 240W max, 30W/per port
Overload current protection: Present
Reverse Polarity Protection: Present
Hi-POT: 1.5KV AC
Physical: Enclosure: IP-30. Weight: 779g
Dimension (W x D x H):
54.3 (W) x 108.3 (D) x 145.1 (H) mm (2.13 x 4.26 x 5.71”)
Environmental: Storage Temperature: -40 to 85°C (-40 to 185°F)
Operating Temperature: -40 to 75°C (-40 to 167°F)
Operating Humidity: 5% to 95% Non-condensing
Regulatory EMC: CE EMC (EN 55024, EN 55032), FCC Part 15 B
approvals: EMI: EN 55032, CISPR32, EN 61000-3-2, EN 61000-3-3, FCC Part 15 B class A
EMS: EN 55024 (IEC/EN 61000-4-2 (ESD: Contact 8KV, Air 10KV), IEC/EN 61000-4-3 (RS), IEC/EN 61000-4-4 (EFT Power 2KV, Single
2KV), IEC/EN 61000-4-5 (Surge: Power 4KV, RJ45 4KV), IEC/EN 61000-4-6 (CS), IEC/EN 61000-4-8(PFMF),
IEC/EN 61000-4-11 (DIP))
Shock: IEC60068-2-27, Free Fall: IEC60068-2-31 HN GP9084-LA
Vibration: IEC60068-2-6, Safety: EN60950-1
MTBF / Warranty: 516416hrs / 5 years
