3/2 and 5/2-way Solenoid Valve for pneumatic

6526 / 6527 • Modular valve block with 16.5 mm 1(P) 3(R)

2(A)
mounting pitch
• Low power consumption
• Rocker pilot in DC
10 4(B) 12
• Fast response times 1(P) 3(R)

4(B) 2(A)
14
12
5(S) 3(R)
1(P)

A compact manifold with a pitch of 16.5 mm per station can be put Envelope Dimensions [mm] (see datasheet for details)
together from the components of Type 6526 / 6527. Type 6526 / 6527

consists of a pilot rocker valve, Type 6106 and a pneumatic seat valve. Type 6526 Type 6527
The rocker principle allows switching of high pressures to gether with low
power consumption and fast response times. All valves are equipped with
manual override as a standard.

Technical Data
Orifice DN6.0 mm
Body material PA (Polyamide)
Seal material NBR
Media Lubricated and non-lubricated dry air; neutral gases
(10 µm filtering)
Media temperature -10 °C to +50 °C C C
Ambient temperature -10 °C to +55 °C
Manual override Standard
Port connection Flange for MP12
Pneumatic module Type MP12 with G 1/8”,
Push-in connection Ø 8 mm
Voltage tolerance ±10%
Voltage 24 V DC
Nominal power 2 W, 1 W
B B
Duty cycle Continuous operation (100% ED) A A
Electrical connection Tag connector acc. to DIN EN 175301-803
(previously DIN 43650) for cable plug, Form C
(not included)
Protection class IP65 (with cable plug) A B C
Weight Type 6526 85 g 16 29 107
Type 6527 95 g
Mounting with 2 screws M3x30
Installation As required, preferably with actuator upright
