Envelope Dimensions [mm] (see datasheet for details)
Steckerbild Steckerbild

DIN 43650 - Form C DIN 43650 - Form C
8 Type 6526 27 8 Type 6527 27
4 4

1
62
62
5,5 ÿ2,1
ÿ 2,1
ÿ2,2 1,1 2,2 ÿ 1,1 5,5 107 14 6526 / 6527
6,2 5,8 107 Ø 3.2 6,2 5,8 ø 3.2 5 1 3 4 2
5,45 8,5 15,8 25,2 5.8 5,45 8,5 15,8 25,2 5.8 5. 8
4,9 67.5 5.8 14.3 4,9 6,6 67.5 14.3
5,45 6,6 13,8 5,45 13,8
6,2 25,2 31,2 (31.2) 6,2 1,1 25,2 31,2 (31.2)
1,1
2,1 26 16 2,2 26 16
5,5 29 5,5 29 17.9

5/2 - Wege Ventil
6527BM01
Ordering Chart 3/2 - Wege Ventil
Pressure Power Response times Item no.
Circuit Orifice QNn value air range consumption
f¸r Ventilinsel
function [mm] [l/min] Opening [ms] Closing [ms] 3) 024 V DC
[bar] [W]
3/2-way solenoid valve without cable plug, Type 6526
700
C 3/2-way 6 6526BM01 1.0 - 10 2 20 12 156 842 2)
valve normally
closed 1.0 - 10 2 20 12 163 028 1)
2.0 - 10 2 20 12 156 318 2)

2.0 - 10 2 20 12 158 944 1)

2.0 - 8.0 1 20 12 158 947 1)
D 3/2-way 6 700 1.0 - 10 2 20 12 163 029 1)
valve normally
open 2.0 - 10 2 12 20 156 320 2)

2.0 - 10 2 20 12 158 946 1)
1) Electrical connection above manual override.
2) “long version”: can be mounted together with Type 6527 on a valve island.
3) In combination with valve islands the closing time will be approx. 5 ms longer.

Power Response times Item no.
Circuit Orifice QNn value air Pressure range consumption
function [mm] [l/min] [bar] Opening [ms] Closing [ms] 3) 024 V DC
[W]
5/2-way solenoid valve without cable plug, Type 6527
H 5/2-way valve 6 700 1.0 - 10 2 20 12 156 828
1.0 - 10 2 20 12 163 030 1)

2.0 - 10 2 20 12 156 337
2.0 - 10 2 20 12 158 942 1)

2.0 - 8.0 1 20 17 156 827

2.0 - 8.0 1 20 12 158 943 1)
1) Electrical connection above manual ride.
2) In combination with valve islands the closing time will be approx. 5 ms longer.
Flow rate, QNn-value air [l/min]: Measured at +20 ºC, 6 bar pressure at value inlet and 1 bar pressure difference
Pressure values [bar]: Measured as overpressure to the atmospheric pressure
Response times [ms]: Measures acc. to ISO 12238
