Programming data
Databit Programming data with 62 Slaves Programming data with 31 Slaves AS-Interface
AS-Interface - apparatus for A/B-Slave-addressing (optional)
(standard device)
E/A - configuration 7 hex (4 Inputs / 4 Outputs) 7 hex (4 Inputs / 4 Outputs)
see bit configuration chart see bit configuration chart
ID-code A hex F hex
8681 combinative ID-code 1 E hex (F hex)
Control head profile S-7.A.E S-7.F.F
7 hex
combinative ID-code 2
(F hex)

Dimensions [mm]
Feedback version (without pilot valves)

1,5 195,5
15,5
96
80 79
31 ±0,1 15

49,3 42,5±0,1
77 11,4±0,1 43,55±0,1
106,7

M16x1,5 (2x)
Secured cap:
- Lead seal max. Ø2
54,4

57,5

7,4 G1/4 (2x)
G1/8 (3x)

Version: 1 to 3 valves
