P. 228
Connections
Without Fieldbus communication 24VDC
Cable glands Cable glands with multipole connection
Version with 12 pin plug (24 V) 1)
Ausführung mit 12 pol. Stecker (für 24 V)
8681
Control head
Connection left: Voltage, signals Connection left: Voltage, signals
Connection right: external initiator Connection right: external initiator
1) M12 plug acc. IEC 61076-2-101, 12 pin at cable 8 cm
With Fieldbus communication AS-Interface
with multipole connection
(M12-plug acc. IEC 61076-2-101, 4-pin)
with mounted flat cable clip at cable 80 cm
ASI-flat cable clip with M12 stainless steel socket
M 12 Plug
outlet
Screws
left: AS-Interface
right: external initiator
227
