Ordering Chart
Item no. Item no.
Electrical Position Controlfunction Actuator series Actuator series
connection feedback pilot valve system Pilot air ports ELEMENT CLASSIC
Type 21xx Type 20xx
Micro switch feedback open/ single-acting (NO/NC) Threaded ports 227 234 227 238
8690 / 8691 switches closed double-acting (springless) Push-in connector external 227 235 227 239
2 micro
M12 connection
G 1/8”
single-acting (NO/NC)
Ø 6 mm or 1/4”
227 212
Push-in connector external
–
Ø 6 mm or 1/4”
none
Push-in connector external
Ø 6 mm or 1/4” 227 197 –
none none – 227 200
1 micro open single-acting (NO/NC) Threaded ports 227 230 –
switch G 1/8”
single-acting (NO/NC) Push-in connector external 227 231 –
Ø 6 mm or 1/4”
double-acting (springless) Push-in connector external 227 210 –
Ø 6 mm or 1/4”
none Push-in connector external 227 194 –
Ø 6 mm or 1/4”
none none – 227 200

Cable gland 2 micro open/ single-acting (NO/NC) Threaded ports 227 232 227 236
switches closed G 1/8”
single-acting (NO/NC) Push-in connector external 227 233 227 237
Ø 6 mm or 1/4”
double-acting (springless) Threaded ports – 227 213
G 1/8”
double-acting (springless) Push-in connector external 227 211 –
Ø 6 mm or 1/4”
none Threaded ports 227 195 –
G 1/8”
none Push-in connector external 227 196 –
Ø 6 mm or 1/4”
none none – 227 198

1 micro open single-acting (NO/NC) Threaded ports 227 228 –
switch G 1/8”
single-acting (NO/NC) Push-in connector external 227 229 –
Ø 6 mm or 1/4”
double-acting (springless) Push-in connector external 227 209 –
Ø 6 mm or 1/4”
none Threaded ports 233 344 –
G 1/8”
none none – 228 284

8691 (other versions on request)
Item no. Cable
Type Item no. M12
Gland / AS-i Clip
Inductive 227 261 227 263

AS-Interface (Push-in 1/4”) 227 259 227 256
DeviceNet (Push-in 1/4”) – 227 257
