Digital electropneumatic positioner
C US

8792 Positioner SideControl • Compact and robust design

• Easy startup using tune function
• No internal air consumption in steady
condition

• Profibus DPV1 or DeviceNet (optional)
• Assembly acc. to IEC 534-6/VDI VDE
3845 or Remote

The robust and compact positioner is designed to standardisation acc. to Envelope Dimensions [mm] (see datasheet for details)
IEC 534-6 or VDI/VDE 3845 for assembly with linear and rotary actua-
tors. In addition, the remote version with the displacement position sensor B
can be combined with Bürkert process control valves. The digital electro- Standard version
pneumatic positioner SideControl can be operated with the usual current A B L
and voltage standard signals and can also be equipped with the Fieldbus L 31 81.9 171.1
interface PROBUS DPV1. Additionally to the digital graphic display the
valve opening is signalled by a mechanical indicator element.

Technical Data
Material
Body Aluminium plastic-coated
Seal EPDM, NBR, FKM A B
Operating voltages 24 VDC +/- 10%
Residual ripple max. 10%
Setpoint setting 0/4 to 20 mA and 0 to 5/10 V L
Input resistance 0/4 to 20 mA: 180 Ω
0 to 5/10 mA: 19 k Ω
Analogue feedback 4-20 mA, 0-20 mA Remote version
0-10 V, 0-5 V A B L
Binary input galvanically isolated, 0-5 V = log “0”, 10-30 V 31 81.9 171.1
= log “1”
Binary output 2 Outputs (optional), galvanically separated
Current limit 100 mA, Output will be synchronised when
overloaded A
Control medium Neutral gases, air DIN ISO 8573-1
Dust concentration Class 5 (<40 µm particle size)
Particle density Class 5 (<10 mg/m ) 3 Technical Data continued
Pressure condensation point Class 3 (<-20°C)
Oil concentration Class 5 (<25 mg/m ) 3 Type of protection IP 65 and IP 67 acc. to EN 60529 (NEMA 4x in
Ambient temperature 0 to +60°C preparation)
Pilot air ports Threaded ports G 1/4” Power consumption < 5 W
Supply pressure 1.4 to 7 bar 1) Electrical connection
Air supply filter Exchangeable (aperture size ~0.1 mm) Multipole connection M12, 8-pin/4-pin; M8, 4-pin
Actuator system single and double-acting to 150 l /min. Cable gland 2xM20x1.5 (cable Ø 10 mm) on screw terminals
N (0.14-1.5 mm )
2
Air capacity 95 l /min (with 1.4 bar ) for aeration and
2)
N Remote version 1xM12x1.5 (cable Ø 3 to 6.5 mm)
ventilation
150 l /min (with 6 bar ) for aeration and Bus communication Profibus DPV1 or DeviceNet
2)
N
ventilation Protection class 3 acc. to VDE 0580
(Q = 100 l /min (acc. to the definition with
Nn N Type of ignition protection II 3 G nA II B T4
decrease in pressure from 7 to 6 bar absolute) II 3 D tD A22 T135°
Position detection module Potentiometer, max. angle 180º Conformity EMV2004/108/EG
Stroke range valve spindle min. 30º on the rotary shaft, depending on lever
CSA approval information
Installation as required, display above or sideways Product category code Class 3221 82-VALVES - Actuators - Certified to
1) The supply pressure has to be 0.5-1 bar above the minimum required pilot pressure for US standards
the valve actuator Class 3221 02-VALVES - Actuators
2) Pressure specifications: Overpressure with respect to atmospheric pressure
Considered standards CAN/CSA-C22 2 No. 139, UL 429
