Technical Data (continued)
Type 8110 8111 Options
Power consumption 1 to 8 VA (AC); 8110
approx. 1.3 W (DC)
Breaking capacitance max. 1250 VA, 50 W • DIN 11851, Flange, SMS
• Higher temperatures on request
Delay time when immersed: 0.5 s
when laid bare: 1s
8111
Blocking current <10 µA
• ATEX approvals
Mode Min./max changeover by Min./max changeover by
electrical connection electrical connection • DIN 11851, Flange, SMS 8110 / 8111
Max.: overfill protection - Max.: overfill protection - • ECTFE, enamel, Hastelloy C4 or PFA
Min.: dry run protection Min.: dry run protection • Higher temperatures on request
LED indication: green
and red
Ambient temperature
Operating -40 °C to +70 °C
Storage -40 °C to +80 °C
Standard
EMC EN 61326 EN61326
Security EN 61010-1 EN61010-1,
1)
ATEX EN50014;
EN50020; EN50284
Specifications Ex
- Protection Categories 1/2G, 2 G
- Certification Ex ia IIC T6
Conformity
specifications 1)
Power supply Ui 20 V
Short circuit rating li 103 mA
Power limitation Pi 516 mW
Ambient temperature -40 °C to +85 °C
(depend on categories)
Internal capacity Ci negligible
Internal inductivity Li negligible
1) homologation certificate PTB 07 ATEX 2004X

Ordering Chart
Process connection Electrical connection Item no.
8110
G 3/4" ISO 228 Multipin M12 555 290

G 1" ISO 228 Multipin M12 555 292
Clamp 2" Multipin M12 555 294

Process connection Electrical connection Item no.
8111
G 3/4” ISO 228 2 x M20 glands 558 110
G 1” ISO 228 2 x M20 glands 558 112

Clamp 2” 2 x M20 glands 558 114

Extension tubes are available (see datasheet Type 8112).
