Dimensions
Pressure connection:

Standard version Flush diaphragm version
G 1/2” A G 1/2” B G 1” B EHEDG G 1” B
A/F 27 A/F 27 A/F 41
8.5 10.5 10.5 A/F 41 8323
31 Sealing ring 31 Sealing ring
20 20.5 18.5 x 23.9 x 1.5 20.5 29.7 x 35.7 x 2.0 50.5
3 10 10 Sealing ring
3 O-ring O-ring 29.7 x 35.7 x 2.0
ø6 ø18-0.1 15 x 2 ø30-0.1 26 x 2 25
ø17.5 G1/2B G1B O-Ring
G1/2A G1B 26.0 x 2.0

48
Weld-on socket for pressure connection flush diaphragm version
G 1/2” B G 1” B EHEDG G 1” B

ø50
110 ø50 ø50 G1
75 G1/2 G 1
ø27
15 -0.2 21 15-0.2 21 25.5

Ordering Chart
Item no.
Pressure Max. Bursting Output
range pressure pressure Power supply signal Standard Standard EHEDG
[bar] [bar] [bar] Standard Flush diaphragm Flush diaphragm Flush diaphragm
G 1/2” B G 1” B G 1” B
0 - 0.10 1 2 10 - 30 V DC 4 - 20 mA 417 692 – 552 063 551 803

0 - 0.16 1.5 2 10 - 30 V DC 4 - 20 mA 417 693 – 552 064 –
0 - 0.25 2 2 10 - 30 V DC 4 - 20 mA 417 694 – – –

0 - 0.40 2 2 10 - 30 V DC 4 - 20 mA 417 695 – 552 065 551 675
0 - 0.60 4 4 10 - 30 V DC 4 - 20 mA 417 696 – – 551 676

0 - 1.00 5 5 10 - 30 V DC 4 - 20 mA 417 697 – 552 066 551 677
0 - 1.60 10 10 10 - 30 V DC 4 - 20 mA 417 698 – – 551 678

0 - 2.50 10 10 10 - 30 V DC 4 - 20 mA 417 699 – – 551 679

0 - 4.00 17 17 10 - 30 V DC 4 - 20 mA 417 700 – – –
0 - 6.00 35 35 10 - 30 V DC 4 - 20 mA 417 701 552 067 – –

0 - 10.0 35 35 10 - 30 V DC 4 - 20 mA 417 702 552 068 – 551 684
0 - 16.0 80 80 10 - 30 V DC 4 - 20 mA 417 703 552 069 – –

0 - 25.0 50 250 10 - 30 V DC 4 - 20 mA 417 704 – – –

Accessories
Description Item no.
Weld-on socket G 1/2” 443 295

Weld-on socket G 1” 444 137
Weld-on socket EHEDG G 1” 443 296
