Ordering Chart
Mounting Sensor Input Controller Setpoint Process Binary UL
position (external) outputs setting value output In/Out Recognition Item no.
Proportional Temperature 1 x PWM 4 - 20 mA 4 - 20 mA 1 x Bin In none 204 642
valve (Pt100) 0 - 10 V 0 - 10 V 1 x Bin Out
Flow rate 1 x PWM 4 - 20 mA 4 - 20 mA 1 x Bin In none 204 639
8611 All sensors with standard signal 1 x PWM 4 - 20 mA 4 - 20 mA (*) 1 x Bin Out none 186 289
(Frequency - NPN)
0 - 10 V
0 - 10 V
1 x Bin In
1 x Bin Out
0 - 10 V
0 - 10 V
(4 - 20 mA / 0 - 10 V)
Panel 2 x Frequency (NPN/PNP) 1 x PWM 4 - 20 mA 4 - 20 mA 1 x Bin In none 210 206
1 x 4 - 20 mA / 0 - 10 V 2 x PTM 0 - 10 V 0 - 10 V 2 x Bin Out
1 x RTD 1 x 4 - 20 mA / UL-Recognized 562 655
0 - 10 V
* Either PWM/PTM or 4-20 mA/0-10 V selectable as PI-control output. If 4-20 mA/0-10 V selected as PI-output, the process value isn’t available.
Accessories (must be ordered separately)
Description Item no.
Positioning system 8810 for pneumatic actuators with rail-mount adaptor 204 458

4-pin M8 female right angle connector with self-locking threaded joint and 2 m molded cable (valve output) 918 718

4-pin M8 female right angle connector with self-locking threaded joint and 5 m molded cable (valve output) 919 412
3-pin M8 female right angle connector with self-locking threaded joint and 2 m molded cable (sensor input) 918 717

3-pin M8 female right angle connector with self-locking threaded joint and 5 m molded cable (sensor input) 919 410

4-pin M8 female connector, straight with snap-on connection and 2 m molded cable (valve output) 919 060
3-pin M8 female connector, straight with snap-on connection and 2 m molded cable (sensor input) 918 039

8-pin M12 female connector, straight with screw connection and 2 m molded cable (PUR) (Power supply) 919 061

8-pin M12 female connector, straight with screw connection, to assemble (Power supply) 918 998
2-pin female connector, straight with 3 m cable (for connection to Positioning system 8810) 133 486

2-pin female connector,straight with 5 m cable (for connection to Positioning system 8810) 167 494
2-pin female connector, straight with 0,3 m wire (for connection to Positioning system 8810) 644 068

2-pin female connector, straight with 0,6 m wire (for connection to Positioning system 8810) 162 144
