Multi-channel, multi-functional transmitter/controller

8619 1/4” DIN Panel Mount

• Flexible analytical and flow transmitter
• Unique flexibility
• Intuitive programming
• SD card for data logging and
upload/download

Bürkert’s 8619 transmitter/controller is the latest addition to the process Envelope Dimensions [mm] (see datasheet for details)
control program. The 1/4DIN panel mounted transmitter/controller

incorporates a large backlit LCD display for adding up to 6 boards in a
free mix for pH, conductivity incl. temperature, and output boards are con- C
nected to the digital inputs of the mainboard.
D
Optional software features can be simply activated when required by the
application and an SD card is standard for data logging and up/down
loading of parameterization files.

Special integrated dosing and control functions allow use in a large range
of applications without the need of additional devices.
A
Technical Data
General data
Mounting panel-mounted B
(stand. 1/4 DIN housing for 92 x 92 mm cutout)
wall-mounted (with mounting plate)
Materials A B C D
Seal / Screws Silicone / Stainless steel 316 102 107 101 11
Support plate for terminals Stainless steel 304
Terminal blocks PBT, contact in gold-plated copper alloy
Display / Front panel and keys PC / Silicone
Housing
Panel-mounted PPO (incl. fastening element) Keypad 4 soft keys [F1] [F2] [F3] [F4] for dynamic functions
Wall-mounted PA66 (incl. fastening plate, cable gland, protecting cover 1 central navigation key with [é] [] [] []
(display), protecting cap (free terminal place), stiffener assignments
hinge) Data logger up to 16 values
Supply 110/240 V AC
terminal protecting cover Stainless steel 304 Sensor monitor Direct display and verification of measured sensor
(wall-mounted version) PVC values
Cover screws (wall-mounted Clock Real-time clock with date
version) Board slots 6
Display LC graphic display, light blue backlighted; Electrical connection Terminal blocks
128 x 168 pixels resolution; German, English, Recommended cable Shielded cable
French languages Solid H05(07) V-U 0.2 to 1.5 mm 2
Flexible H05(07) V-K 0.2 to 1.5 mm 2
With wire end ferrule 0.2 to 1.5 mm 2
With plastic collar ferrule 0.2 to 1.5 mm 2

400
