Ordering Chart
Item no. per Voltage/frequency [V/Hz]
Kv value Kv value QNn- Pressure
Orifice Electrical Cycling function
Circuit function water ll water value air range
[mm] connection monostable bistable (impulse)
3
[m /h] [l/min] [l/min] [bar]
012/DC* 024/DC* 06/DC* 012/DC*
Valves with flange
A 2/2-way valve, 0.6 0.006 0.1 6.4 Vac. - 3 Rectangular plug 145 467 140 464 140 467 143 170 6604
normally closed 5.08 mm
Flying leads 140 465 140 466 140 468 145 467
300 mm
T 3/2-way valve, 0.6 0.006 0.1 6.4 Vac. - 3 Rectangular plug. 140 469 140 470 140 473 141 388
universal function 5.08 mm
Flying leads 140 471 140 472 140 474 145 470
300 mm

Accessories

Description Feature Item no.
Rectangular cable plug with 3 m cable 133 486

with 300 mm flying leady 644 068
with 2 single contacts 644 067

Quantity of valves places Dimensions A [mm] Item no.
Manifolds for Type 6604
Single manifold in stainless steel 10 644 684

2 valves 33 659 285
3 valves 44 659 286

4 valves 55 659 287

5 valves 66 653 131
6 valves 77 659 288

7 valves 88 659 289

8 valves 99 659 290
9 valves 110 659 291

10 valves 121 651 379

Manifold dimensions [mm]

Single manifold M3, stainless steel Multi-station manifold, PEEK
A
4,5 4x M1,6
9
3x M3 11 2,75 2,75
Ø 1,2
25 4 21,5
4
3,2 32 UNF 1/4-28

8 10
(N-1)x11 (UNF 1/4-28)
No. of valve
positions 2 3 4 5 6 7 8 9 10
Dimensions 33 44 55 66 77 88 99 110 121
A [mm]

85
