Ordering chart
Voltage Sensor Electrical
Description Output Relay Item no.
supply version connection
Compact Flowmeter Type 8025T
Standard output signal flowmeter, 12 - 30 V DC 4 - 20 mA (2-wire) none Hall, short DIN EN 175301-803 418 762
2 totalizers + pulse
2 cable glands 418 802 8025
Hall, long DIN EN 175301-803 418 763

2 cable glands 418 803

4 - 20 mA (3-wire) 2 Hall, short 2 cable glands 418 778 INSERTION COMPACT
+ pulse
Hall, long 2 cable glands 418 779

115 - 230 V AC 4 - 20 mA (2-wire) none Hall, short 2 cable glands 418 423
+ pulse
Hall, long 2 cable glands 418 424

4 - 20 mA (3-wire) 2 Hall, short 2 cable glands 418 431
+ pulse
Hall, long 2 cable glands 418 432
Indicator, 2 totalizers 2 x 9 V DC none none Coil, short none 418 403
battery
Coil, long none 418 405

Note regarding the ordering of a complete sensor for the Type 8025T remote Transmitter:
Please enter the appropriate sensor according to the Technical Data table regarding compatibility and select and order the respective INSERTION fitting
and the selected sensor separately.

DN20 Short sensor DN50 DN65 DN100 DN200 DN350 DN400
Available S020 fitting DN Weld-in socket Short sensor Long sensor
T-fitting

Short sensor
Long sensor
Fusion spigot

Long sensor
Screw-on S020
Saddle
Long sensor

Accessories

Description Item no.
Set with 2 cable glands M20 x 1.5 + 2 neoprene flat seals for cable gland or plug + 2 screw-plugs M20 x 1.5 + 2 multiway seals 449 755
2 x 6 mm
Set with 2 reductions M20 x 1.5 /NPT1/2” + 2 neoprene flat seals for cable gland or plug + 2 screw-plugs M20 x 1.5 551 782

Set with 1 stopper for unused cable gland M20 x 1.5 + 1 multiway seal 2 x 6 mm for cable gland + 1 black EPDM seal for the sen- 551 775
sor + 1 mounting instruction sheet
Ring 619 205
Union nut 619 204

Set with 1 green FKM and 1 black EPDM seal 552 111

Cable plug DIN EN 175301-803 with cable gland (Type 2508) 438 811
Cable plug DIN EN 175301-803 with NPT1/2” reduction without cable gland (Type 2509) 162 673
