Ordering Chart
Supply voltage Inputs Outputs Electrical Connection Item no
Switch electronic module, Type SE32
12 - 30V DC none Transistor NPN Cable plug DIN EN 175301-803 436 474

Transistor PNP Cable plug DIN EN 175301-803 434 871
8072 Transistor NPN / PNP 5-pin plug M12 (adjustable) 436 473

Relay 5-pin plug M12 (adjustable) and cable plug 436 475
DIN EN 175301-803
4 - 20 mA1) 4 - 20 mA2) + Relay 8-pin plug M12 (adjustable) and cable plug 444 699
DIN EN 175301-803
1) External setpoint 2) Process value

Accessories
Description Item no.
Female M12 connector, 5 pins, with plastic threaded locking ring 917 116
Female M12 connector, 5 pins, moulded on cable (2 m, shielded) 438 680

Female M12 connector, 8 pins, with plastic threaded locking ring 444 799
Female M12 connector, 8 pins, moulded on cable (2 m, shielded) 444 800

Cable plug EN 175301-803 with cable gland (Type 2508) 438 811

Cable plug EN 175301-803 with NPT 1/2“ reduction without cable gland (Type 2509) 162 673

Spare parts for fitting Orifice Material Item no.
[mm] [inch]
Oval Wheel DN 15 1/2 PPS 550 933

Stainless steel 550 934
DN 25 1 PPS 550 937

Stainless steel 550 938

DN 40 1 1/2 PPS 550 941
Stainless steel 550 942

DN 50 2 PPS 550 945
Stainless steel 550 946

O-Ring DN 15 1/2 EPDM 550 929

FKM 550 930
DN 25 1 EPDM 550 935

FKM 550 936

DN 40 1 1/2 EPDM 550 939
FKM 550 940

DN 50 2 EPDM 550 943

FKM 550 944
