Technical Data (continued) Pressure / temperature chart
General data
Pressure
Compatibility Any pipe from which are fitted out with Bürkert (bar) B A
adaptor S022 (see separate data sheet) 16
15
Materials See exploded view, opposite 14 PVDF
Housing Stainless steel 1.4561 (316L), PPS 13 PVC
12
Cover PPS 11
10
Seals EPDM 9 8
Fixed connector/cable PA66 7 PVDF
gland 6 5
Nut PVC (PVDF on request) 4 3
Wetted part materials 2 1
Sensor holder PVDF, Stainless steel 1.4571 (316Ti) 0 -20 0 +20 +40 +60 +80 +100 +120 +140 T °C
Probe See probe specific technical data 8202 ELEMENT neutrino
Probe 120 mm Bürkert pH or ORP probe Type 8203 Application range of a 8202 ELEMENT neutrino transmitter:
or any combined 120 mm pH or ORP probe, A : with PVDF nut (on request)
without temperature sensor, with PG13.5 head, B : with PVC nut
The measures have been made at an ambient temperature of 60 °C,
S7/S8 connector without probe.
Temperature sensor Pt1000 integrated within the holder
Electrical connections 1x 5-pin M12 male fixed connector,
or Terminal strip via 1x cable gland M16x1.5
Recommended connection Shielded cable Application range of a 8202 ELEMENT neutrino transmitter
cable for terminal strip (Measuring data acc. to CEI 664-1/VDE 0110 (without probe)
(4.97))
Solid H05(07) V-U 0.25 up to 1.5 mm 2 - with PVC nut with S022 adaptor
Flexible H05(07) V-K 0.25 up to 1.5 mm 2 P (bar)
With wire end ferrule 0.25 up to 1.5 mm 2 16
15
With plastic collar ferrule 0.25 up to 0.75 mm 2 14 Metal
13
Diameter 4 to 8 mm 12
11
Standards, directives and approvals 10
9
Protection class IP65, IP67, NEMA 4X and NEMA 6P, with M12 8 7 PVC +
cable plug or cable gland tightened or obturated 6 5 PP
and cover properly mounted and secured 4
3
Standard and directives 2 1
EMC EN 61000-6-2, EN 61000-6-3 0 -10 +10 +30 +50 (T °C)
Pressure Complying with article 3 of §3 from 97/23/CE
directive.*
Vibration / Shock EN 60068-2-6 / EN 60068-2-27
- with PVDF nut with S022 adaptor
* For the 97/23/CE pressure directive, the device can only be used under following conditions P (bar)
(depend on max. pressure, pipe diameter, type of probe and fluid). 16
15
14
13
12 Metal
11
Envelope Dimensions [mm] (continued) 10
9
8
7 PVC + PP
86 6
94 5 4
86.5 Ø 59.5 56 3 PVC
56.5 2
1 PP
0
-10 +10 +30 +50 +70 +90 +110 +130 T °C
199 213
276.5
49.5 Ø75

G1"1/2

375
