Technical data (continued) Pressure/temperature chart
Electrical connections 1x 5-pin M12 male fixed connector,
or terminal strip via 1x cable gland M16x1.5
Recommended connection Shielded cable Pressure
cable for terminal strip (Measuring data acc. to CEI 664-1/VDE (bar) A
0110 (4.97)) 16 B
Solid H05(07) V-U 0.25 to 1.5 mm 2 15 PVDF
14
Flexible H05(07) V-K 0.25 to 1.5 mm 2 13 PVC
With wire end ferrule 0.25 to 1.5 mm 2 12
11
With plastic collar ferrule 0.25 to 0.75 mm 2 10 9
Diameter 4 to 8 mm 8
7 PVDF
Standards, directives and approvals 6
5
Protection class IP65, IP67, NEMA 4X and NEMA 6P with 4 3
M12 cable plug or cable gland tightened or 2 1 8222 ELEMENT neutrino
obturated and cover properly mounted and 0 -20 0 +20 +40 +60 +80 +100 +120 +140 T °C
secured
Standard and directives
EMC EN 61000-6-2, EN 61000-6-3 Application range of a 8222 ELEMENT neutrino conductivity meter:
Pressure Complying with article 3 of §3 from 97/23/ A : with PVDF nut (on request) or G¾” external threaded connection
CE directive.* B : with PVC nut
Vibration / Shock EN 60068-2-6 / EN 60068-2-27 The measures have been made at an ambient temperature of 60 °C.
* For the 97/23/CE pressure directive, the device can only be used under following conditions
(depend on max. pressure, pipe diameter and fluid).

10 1 0.1 0.01 1 0.1
50 20 5 2 0.5 0.2 0.05 0.02 0.005 0.002 0.5 0.2 Application range of a 8222 ELEMENT neutrino conductivity meter
- with PVC nut with S022 adaptor
C=1.0
P (bar)
C=0.1 16
15
14 Metall
C=0.01 13
12
11
10
0.02 0.05 0.1 0.2 0.5 1 2 5 10 20 50 100 200 500 1 2 5 10 9 8 7 PVC +
mS/cm
5 6 PP
Ultra Pure Industrial Sewage 4 3
pure water water 2 1
water 0
-10 +10 +30 +50 (T °C)
This diagram shows the ranges of the different cell constants of the sensors.

- with PVDF nut (on request) with S022 adaptor
P (bar)
16
15
14
13
12 Metall
11
10
9
8
7 PVC + PP
6
5
4 PVC
3
2
1 PP
0
-10 +10 +30 +50 +70 +90 +110 +130 T °C
- with G ¾ threaded connection with S022 adaptor
P (bar)
16
15
14
13 Metall
12
11
10
9
8
7 PVC
6
5
4 PVC
3
2
1
0
-10 +10 +30 +50 +70 +90 +110 T °C
