Accessories
Article Item No.
Connections/Cables
Socket D-Sub 15-pin solder connection 918 274

Hood for D-Sub socket, with screw locking 918 408
8701
Socket D-Sub 15-pin with 5 m cable 787 737

Socket D-Sub 15-pin with 10 m cable 787 738

Adapters 1)
RS232 adapter (for connection of a PC, in combination with the PC cable) 654 748

PC extension cable for RS232 9-pin socket/plug 2 m 917 039
RS422 adapter (RS485 compatible) 666 371

USB adapter (Version 1.1, USB socket type B) 670 639

Communication software MassFlowCommunicator Download from
www.buerkert.com
PROFIBUS DP DeviceNet, CANopen
Accessories for Fieldbus
(B-coded) (A-coded)
Plug M12 2) 918 198 917 115
Socket M12 2) 918 447 917 116

Y-junction 2) 902 098 788 643
Terminating resistor 902 553 (on request)

GSD-File (PROFIBUS), EDS-File (DeviceNet, CANopen) Download from www.buerkert.com (see Type 8701)
1) The adapters serve mainly for initial operation or diagnosis. Those are not obligatory for continuous operation.
2) The two M12 connectors as listed above cannot be used together on the same side of the Y-junction. At least one of the two M12 connection needs to be an overmoulded cable which uses
typically a thinner connector. A T-junction cannot be used together with this type of MFM.
