Page 414 - Bürkert
P. 414
Dimensions [mm] (see datasheet for more details)
2x M4 - 10 tief
23 Size A
G 1/4”
3.8 97
2.4 8702
137
71
A
A 42
12.5 25
12 12 3.9
115 1.9 29.2
37
Ordering chart
Signal
Flow rate - Full Base block Operating pressure
Operating gas Seal material actual value Item no.
scale Stainless steel [bar(g)]
output
Type 8702
Air 10 lN/min yes FKM 6 4 - 20 mA 214 514
Air 25 lN/min yes FKM 6 4 - 20 mA 168 115
Air 50 lN/min yes FKM 6 4 - 20 mA 202 678
