Ordering chart
Operating Signal
Flow rate - Base block
Operating gas Seal material pressure actual value Item no.
Full scale Aluminium
[bar(ü)] output
Type 8701
Air 100 cm³N/min x FKM 1 4 - 20 mA 180 866
8701 Air 500 cm³N/min x FKM 1 4 - 20 mA 219 568

Air 1 lN/min x FKM 3 0 - 10 V 226 222

Air 5 lN/min x FKM 1 0 - 10 V 202 858

Air 10 lN/min x FKM 5 4 - 20 mA 252 074
Air 25 lN/min x FKM 5 4 - 20 mA 171 006

Air 50 lN/min x FKM 5 4 - 20 mA 174 412

Air 80 lN/min x FKM 5 4 - 20 mA 241 884
Hydrogen 1 lN/min x FKM 5 4 - 20 mA 251 554

Hydrogen 10 lN/min x FKM 2 0 - 10 V 235 503

Hydrogen 100 lN/min x FKM 4 4 - 20 mA 182 567
Hydrogen 200 lN/min x FKM 4 4 - 20 mA 212 355

Dioxygen 20 lN/min x FKM 4 4 - 20 mA 253 550
Dioxygen 3 m³N/h x FKM 4 4 - 20 mA 181 207

Argon 10 lN/min x FKM 5 4 - 20 mA 235 159

Argon 30 lN/min x FKM 4 4 - 20 mA 174 419

Notes regarding the selection of the unit
The decisive factors for the perfect functioning of an MFM within the application are the fluid compatibility, the normal inlet pressure and the correct
choice of the flow meter range. The pressure drop over the MFM depends on the flow rate and the operating pressure.
