Ordering Chart
Pressure Voltage/ Power
Circuit Orifice QNn value range Service port frequency consumption Item no. Item no.
function [mm] air [l/min] 2 and 4 DC coil nn UC coil nnn
[bar] [V/Hz] [W]
Extendable single valve with module flange for supply ports 1 and 3, tag connector above, supplied without cable plug
C 3/2-way 4.0 300 2-10 Push-in connection 024/DC/UC 2 136 872 –
5470 R closed n check valve (Op- 220-240/DC/UC 3 136 874 145 971
Ø 6 mm below with
valve, normally
tion A)
G 4/2-way
(Option E)
valve 4.0 300 2-10 G 1/8" at side 024/DC/UC 2 136 881 –
220-240/DC/UC 3 136 883 145 980
G 1/8" at side with 024/DC/UC 2 136 884 –
one-way flow
restrictor 220-240/DC/UC 3 136 886 145 983
(Option B)
Push-in connection 024/DC/UC 2 136 887 –
Ø 6 mm at side
(Option F) 220-240/DC/UC 3 136 889 145 986
Push-in connection 024/DC/UC 2 136 890 –
Ø 6 mm under-
neath 220-240/DC/UC 3 136 892 145 989
(Option C)
n 3/2-way models with non-returrn valve in the module flange
nn Only for direct current operation (DC), for alternating current (AC), place a cable plug with a rectifier upstream
nnn For universal current operation (UC = DC or AC); rectifier, varistor and LED integrated into the coil

Voltage/ Power
Circuit Orifice QNn value Pressure Service port Item no.
function [mm] air [l/min] range [bar] 2 and 4 frequency [V/ consumption DC coil
Hz] [W]
Extendable single valves with module flange for supply ports 1 and 3, with rectangular plug
C 3/2-way 4.0 300 2-10 Push-in connection Ø 6 mm 024/DC 2 145 993
valve, normally under with RSV (Option A) n
closed
G 4/2-way 4.0 300 2-10 G 1/8" with 1-way restrictor valve 024/DC 2 145 997
valve (Option B)
Push-in connection Ø 6 mm on 024/DC 2 145 998
side (Option F)
Push-in connection Ø 6 mm 024/DC 2 145 999
underneath (Option C)
n RSV = non-return valve
