Technical data (continued)
Environment
Height above sea level Max. 2000 m
Relative humidity ≤ 80%, without condensation
Ambient temperature -10 °C to +60 °C (32 to 140°F) (operation and storage)
Standards, directives and approvals
Protection class IP65 (panel-mounted and wall-mounted version) de-
vice wired and cable glands tightened screwed tight
IP20 (panel-mounted version, inside the cabinet)
Approvals CE remote Version
Standard 8025 Transmitter
EMC EN 61000-6-2, EN 61000-6-3
Safety EN 61010-1
Vibration EN 60068-2-6
Shock EN 60068-2-27
Specific technical data of UL-recognized products for US and Canada
Relay output 30 V AC and 42 V peak max. or 60 V DC max.
Ambient temperature -10 °C to +60 °C (14 to 140°F)
Relative humidity max. 80 %, without condensation
Intended for an inner Grade of pollution 2, according to EN61010-1
pollution
Installation category Category I, according to UL61010-1
Dimensions [mm]
38
88
Panel-mounted version
76 25
88
126
Wall-mounted version
120
90
143
31.50
23 23
