Ordering Chart
Item no.
Description Voltage supply Output Electrical connection
without display with display
For compact transmitter, Type SE36
2 outputs 14 - 36 V DC 1 x Transistor NPN 5-pin M12 male fixed connector 560 880 561 880
+ 1 x 4-20 mA male fixed connector
8036 3 outputs 14 - 36 V DC 2 x Transistor NPN/PNP 5-pin M12 male fixed connector 560 881 561 881
(2-wire)
+ 1 x 4-20 mA
(2-wire) male fixed connector
4 outputs 12 - 36 V DC 2 x Transistor NPN/PNP 1 x 5-pin M12 male + 1 x 5-pin 560 882 561 882
+ 2 x 4-20 mA M12 female fixed connector
(3-wire)

Accessories

Specification Item no.
Removable display/programmer module (with instruction sheet) 559 168

Black blank cover with EPDM seal 560 948

Transparent cover with EPDM seal 561 843
5 pin M12 female straight cable plug with plastic threaded locking ring, to be wired 917 116

5 pin M12 male straight cable plug with plastic threaded locking ring, to be wired 560 946
5 pin M12 female straight cable plug moulded on cable (2 m, shielded) 438 680

5 pin M12 male straight cable plug moulded on cable (2 m, shielded) 559 177

Note about ordering table
To select an entire device the following order items are required:
• Product no. of the desired compact flow transmitter, Type SE36
• Product no. of the selected INLINE fitting, Type S030, must be ordered separately

Important
Please be careful when ordering devices without a display, that you purchase at least one display module.
