Technical Data (continued) Pressure / temperature chart
Electrical data
P (bar)
Power supply (V+) 12 - 36 V DC (max tolerance: -5% or +10% at 11 A
12 V DC; ±10% at 36 V DC), filtered and regu-
lated, SELV (safety extra low voltage), circuit with a 10
non dangerous energy level or 9 PVDF Metal
115/230 V AC 50/60 Hz (see technical specifica-
tions 115/230 V AC) 8 PVC + PP PVDF (PN10)
Reversed polarity of DC protected 7
Current consumption with with relays 6
sensor ≤ 90 mA at 12 V DC;
(without consumption of ≤ 45 mA at 36 V DC 5
digital input and pulse 4 PVC (PN10) 8035 Batch Controller
output)
3
Inputs DI (1 to 4) Switching threshold Von: 5... 36 V DC;
Switching threshold Voff max: 2 V DC; 2
Input impedance: 9.4 KOhms; 1 PP (PN10)
Galvanic insulation, protected against polarity 0 T (°C)
reversals and voltage spike -10 +10 +30 +50 +70
Outputs
Transistors (DO1 and NPN or PNP (wiring dependent), potential free; A: Application range for complete device (Fitting + Transmitter)
DO4) function: pulse output (by default for DO1), batch
state (by default for DO4), configurable and
parameterizable
0.6 - 2200 Hz, 5 - 36 V DC, 100 mA max.,
line drop 2.7 V DC at 100 mA
duty cycle:
> 0.45 if 0.6 < frequency < 300 Hz
> 0.4 if 300 < frequency < 1500 Hz
< 0.4 if 1500 < frequency < 2200 Hz
Galvanic insulation, protected against overvoltage,
polarity reversals and short-circuits

2 relays (normally open), parameterizable (by
default: DO2 always configured to control the
valve, parameterized of 100% of the batch quantity
Relays (DO2 and DO3) and DO3 configured as alarm), 230 V AC/3 A or
40 V DC/3 A (resistive load), max. cutting power of
750 VA (resistive load)
Technical specifications 115/230 V AC
Voltage supply 27 V DC regulated
available inside the max. current: 125 mA
device integrated protection: fuse 125 mA temporised
power: 3 VA
Environment
Ambient temperature -10 to +60°C (14 to 140°F) (version
(operation and storage) 12 - 36 V DC)
-10 to +50°C (14 to 122°F) (version
115/230 V AC)
Height above sea level max. 2000 m
Relative humidity ≤ 80 %, without condensation
Standards, directives and approvals
Protection class IP65 with cable gland mounted and tightened or
(according to EN60529) with obturator locked if not used.
Standard and directives
EMC EN 61000-6-2, EN 61000-6-3
Security EN 61010-1
Pressure (Fitting S030,
DN06 to DN65, in PVC, Complying with article 3 of chap. 3 from 97/23/
PP, PVDF, stainless CE directive.*
steel or brass) EN 60068-2-6
Vibration EN 60068-2-27
Shock
Approvals CE; UL-Recognized for US and Canada (61010-1
+ CAN/CSA-C22 No.61010-1)
