Dimensions [mm] (see datasheet for more details)

True union process connection
DIN 8063, DIN 16962 in PP or ISO 10931 in PVDF
P
A
DN [mm] 128.0 [mm] [mm] [mm] [mm] P
D1
A1
D
A2
[mm]
[mm]
S020 Fittings 20 77.8 144.0 106 100 25.00 53 D D1
15
80.4
96
20.00
43
90
116
32.00
160.0
25
60
110
78.0
40.00
168.0
116
74
81.4
32
110
127
85.2
40
120
50.00
188.0
83
A2
91.5
130
212.0
50
136
A1
103
63.00
A
Note: short sensor version
Internal thread process connection
G in stainless steel (316L - 1.4404) or brass (CuZn39Pb2)
DN P A D L
[mm] [mm] [mm] [inch] [mm]
P
15 80.3 84.0 G 1/2 16.0
20 77.8 94.0 G 3/4 17.0
25 78.0 104.0 G 1 23.5 D
32 81.6 119.0 G 1 1/4 23.5
40 85.4 129.0 G 1 1/2 23.5 L
50 91.5 148.5 G 2 27.5 A
Note: short sensor version
Welding socket with radius
in stainless steel (316L - 1.4404)
DN A B R
[mm] [mm] [mm] [mm]
50 56.6 61.6 30.2
65 54.5 58.6 36.7
80 53.1 56.4 44.5
100 50.7 53.2 57.2 A +0.1
125 48.2 50.3 70.7 B
150 45.7 47.4 84.2
200 41.0 42.3 109.6
250 73.6 74.7 136.6
300 67.8 68.7 162.0 R0.5 R
350 63.9 64.7 177.8
Note: sensor version:
- short for DN50 - DN200
- long for DN250 - DN350
Saddle
in PP & PVC
DN P H D D1
[mm] [mm] [mm] [mm] [mm]
P
50 116.0 155 116 63
65 115.0 160 129 75 H
80 119.0 171 144 90
100 124.0 187 166 110
110 120.0 191 181 125
125 127.0 205 196 140
150 137.0 225 216 160 D1 D
180 161.0 271 266 200
200 173.0 291 290 225
Note: long sensor version Body material: PP & PVC adapter
Seal material: EPDM
