Fittings for Type 8202 pH-value/ORP and
Type 8222 Conductivity Sensors

S022 Fittings DN32-110 mm adapters for pipe and
tank mount fittings

• Simple installation guaranteed

• Modular concept for pH,
ORP and conductivity

Fittings to connect the compact analytical transmitters to the media. Envelope Dimensions [mm] (see datasheet for details)
Materials included are PVC-U, PP, Stainless steel, and PVC thread. For
chemical resistance details please download our chemical resistance 1 G 1" 1/2 2 G 1" 1/2
booklet from our website www.burkert.com
17 15.2
Technical Data
43 52
General data
Pipe diameter DN06 (with reduction) to DN110 (plastic) or bigger
(stainless steel)
Process connection 4.55
Adapter Solvent, fusion, welding, threaded and to connect with Ø33.4 Ø24.3
screws Ø33.7
Fitting Metric or ASTM True union or weld ends; saddle Ø44.4
Materials 3
Adapter PVC, PP, stainless steel - delivered with 2 seals,
1 FKM and EPDM 18
Fitting 36
Seal FKM, EPDM
Body & adapter PVC&PVC, PP&PVC
Medium data
Medium temperature See pressure-temperature chart on next page. Ø24.3
Temperature limits may depend on inserted measur- G 1" 1/4
1)
ing device .
Medium pressure PN10 (plastic) or PN16 (metal).
(max.) Pressure limits may depend on inserted measuring
device . Pressure / temperature chart
1)
Environment
Ambient temperature Temperature limits may depend on inserted measur- 232
1)
ing device . 215 Metal (PN16)
Standards, directives and approvals 200
188
Directive - Pressure Complying with article 3 of §3 from 97/23/CE 175
directive.* 160
1) Please refer to appropriate instruction manual or data sheet for more details. 145
130
* For the 97/23/CE pressure directive, the device can only be used under following conditions Pressure [bar] 115 PVC + PP
(dependent on max. pressure, pipe diameter and fluid). 100
87
Type of fluid Conditions 72 PVC (PN10)
60
Fluid group 1, §1.3.a Only DN ≤ 25 45
Fluid group 2, §1.3.a DN ≤ 32, or DN > 32 and PN*DN ≤ 1000 30 PP (PN10)
15
Fluid group 1, §1.3.b DN ≤ 25, or DN > 25 and PN*DN ≤ 2000 0
-10 +10 +30 +50 +70 +90 +110 +130
Fluid group 2, §1.3.b DN ≤ 125 Temperature [°C]
Note: Always take lowest max. medium temp. of both adapter and chosen ELEMENT transmitter.
