INLINE Flowmeter for Continuous Flow Measurement

SE30 For use with fitting S030, DN15-50 mm

• Turn & Lock bayonet fitting isolates
sensor from media
• Economic integration in pipe systems
• 3-wire frequency version for direct
connection to PLC (PNP and NPN)
• Connection to Bürkert evaluators in
remote versions
Please see fitting S030

Unique bayonet style flow meter constructed from an SE30 sensor and an Envelope Dimensions [mm] (see datasheet for details)
S030 flow fitting. Perfect for neutral, solid free liquids. A hall-effect sensor
produces a square wave frequency proportional to the flow rate.

Technical Data (Standard)
General data
Compatibility With fittings S030 (see corresp. datasheet)
Materials
Housing, cover, male fixed conn. PC
Cable plug / seal / screws PA / NBR / Stainless steel
Wetted parts materials
Fitting, sensor armature Brass, stainless steel 1.4404/316L,
PVC, PP, PVDF
Paddle wheel PVDF
Axis, bearing / Seal Ceramics / FKM or EPDM (
depending on Sensor-Fitting version) A B C
44 54 66
Electrical connection Cable plug EN 175301-803 (Type 2508)
(included in delivery)
Connection cable max. 1.5 mm cross section; max. 50 m length,
2
shielded
Complete device data (fitting + electronic module) Electrical data
Pipe diameter DN06 to DN65
Operating voltage 12 - 36 V DC filtered and regulated (via Bürkert
Measuring range 0.3 to 10 m/s transmitter the device is connected for “Low Power”
Medium temp. with fitting in version)
PVC / PP 0 to 50°C / 0 to 80°C Current consumption with sensor
Stainless steel, brass, PVDF -15 to 100°C Hall version ≤ 30 mA
Medium pressure max. PN10 (with plastic fitting) PN16 (with metal fitting) Hall “Low power” version ≤ 0.8 mA
(PN40 on request, see S030 data sheet) Output: Frequency
Viscosity / Pollution 300 cSt. max. / max. 1% Hall version 2 transistors NPN and PNP, open collector,
(Size of particles 0.5 mm max.) max. 100 mA,
Measurement error frequency: 0 to 300 Hz; duty cycle 1/2 ±10%
1)
Teach-In ±1% of Reading (at the teach flow rate value) NPN output: 0.2-36 V DC
Standard K-factor ±2.5% of Reading 1) PNP output: supply voltage
Linearity ±0.5% of F.S.* 1) Hall “Low Power” version 1 transistor NPN, open collector, max. 10 mA,
frequency: 0 to 300 Hz; duty cycle 1/2 ±10%
Repeatability ±0.4% of Reading 1)
Dielectric strength 2300 V AC
Environment Reversed polarity of DC Protected
Ambient temperature -15 to + 60°C (5 to 140°F) (operating and storage) Standards and approvals
Relative humidity ≤ 80%, without condensation
Protection class IP65 with connector plugged-in and tightened
* F.S. = Full scale (10 m/s) Standard and directives
1) Under reference conditions i.e. measuring fluid = water, ambient and water temperature EMC EN 61000-6-2, 61000-6-3
= 20°C (68°F), applying the minimum inlet and outlet pipe straights, matched inside pipe Pressure Complying with article 3 of §3 from 97/23/
dimensions. CE directive.*
Vibration EN 60068-2-6
Shock EN 60068-2-27
